• JoinTech IceMaster G40 glycol chiller, 4 pumps, 30 L reservoir, front view
  • JoinTech IceMaster G40 glycol chiller, four digital temperature controllers
  • JoinTech IceMaster G40 glycol chiller, 1/2 inch dry-break fittings
  • JoinTech IceMaster G40 glycol chiller, 410 x 410 x 660 mm, caster wheels
  • JoinTech IceMaster G40 glycol chiller, reservoir with removable lid
1 5

KegLand

JoinTech Fermentation Glycol Chiller with Digital Control | 4 Pump Model | Icemaster G40

JoinTech Fermentation Glycol Chiller with Digital Control | 4 Pump Model | Icemaster G40

€1,099.00 EUR
€1,099.00 EUR
Sale Sold out
Taxes included.
Ships within 7 days of your order

🚛 Ships on a pallet · 32 kg · Shipping to Germany: €49

Delivery 3–5 business days · Shipping details · Free shipping over €149 does not apply to fermenters, kettles and other large items

Crew Earns 1099 Crew points · How it works

Pairs well with

  • Leak Free Cooling Kit! for Jacketed Fermenters Leak Free Cooling Kit! for Jacketed Fermenters Only 1 leftView details €199.00
  • 1/2 inch female quick disconnect stainless steel fitting with 13.1mm hose barb 1/2 female quick disconnect with bar OD 13.1 5+ in stockView details €19.95
  • Food Grade Glycol 5L Food Grade Glycol 5L 5+ in stockView details €59.95
  • Insulation tube for hose 9x12 - 2m Insulation tube for hose 9x12 - 2m 5+ in stockView details €6.95
  • INKBIRD ITC-308 WiFi INKBIRD ITC-308 WiFi 5+ in stockView details €79.00

Read customer reviews · ✓ 2-year EU warranty

Four fermenters, four temperatures, one chiller.

The JoinTech IceMaster G40 is a compact, compressor-driven glycol chiller for homebrewers and small craft breweries. Four built-in submersible pumps, each with its own digital controller, let you run up to four fermenters or brite tanks at different temperatures at once — one vessel fermenting at ale temperature while another cold crashes. Compressor cooling is 3–6× more efficient than thermoelectric and holds up in a warm garage or brewery.

Key points

  • 780W (1 HP) compressor cooling, R600a refrigerant
  • 4 integrated pumps, each with its own temperature controller
  • 30L reservoir with removable lid; reservoir set point on the built-in STC-1000
  • JoinTech 1/2" dry-break male fittings; 4 temperature probes (3 m) included
  • Caster wheels included
  • Fermentation capacity ~240 L · cold crash ~70 L

Setup & use

Use propylene glycol at ~20% for freeze protection to about -8°C and set the reservoir to around -4°C. Connect with matching 1/2" dry-break female fittings and 13mm ID hose (sold separately). The controller supports heating output via integrated terminals — wiring a heating device is a job for a qualified electrician.

Protect the compressor: only chill wort with the G40 after it's already below 50°C (cooled with water first). Leave at least 100mm clearance around the vents and clean the radiator regularly.

Cools jacketed fermenters and coil-equipped tanks · Two-pump version: IceMaster G20.2 · See all Glycol Chillers

Specifications

Cooling type / power Compressor · 780W (1 HP)
Refrigerant R600a (isobutane)
Reservoir 30 L (enclosed, removable lid)
Pumps 4 integrated, independent control
Max head / flow (per pump) 5 m · 600 L/h
Fittings JoinTech 1/2" dry-break male (use 1/2" dry-break female + 13 mm ID hose)
Temperature probes 4 × 3 m, 4 mm OD
Power draw 210 W
Dimensions (L×W×H) 410 × 410 × 660 mm
Mobility Caster wheels included
Capacity guide Fermenting ~240 L · cold crash ~70 L

Figures are totals for all connected tanks and assume insulated jacketed tanks and glycol lines, a room up to 25 °C and a cold crash from 20 to 2 °C in 24 hours. Fermenting and crashing share the same cooling power. Bare steel tanks or a warmer room can halve these figures; over 48 hours a crash handles about 1.7× the volume.

What's in the box

  • G40 chiller with 4 pumps, 4 temperature probes and caster wheels

Not included: tubing, 1/2" dry-break female fittings, propylene glycol.
