Lindr

Lindr AS-110 GLYCOL GREEN LINE

Lindr AS-110 GLYCOL GREEN LINE

Regular price €1.199,00 EUR
Regular price Sale price €1.199,00 EUR
Sale Sold out
Taxes included.

Low stock: 1 left

FREE SHIPPING

In an external warehouse. We ship within 7 days after order.

Characteristic Lindr AS-40 Lindr AS-80 Lindr AS-110 NEW GREEN LINE Lindr AS-200 NEW GREEN LINE Lindr CWP 300
Capacity (0°C) [BTUs/hr] 1057 2149 2934 6824 7847
Fermenting [liter] 382 938 1207 ~2414 ~2776
Cold Crash [liter] 95 134 201 ~402 ~462

The AS-110 GLYCOL NEW GREEN LINE cooler is equipped with 2x digital thermostat with a range of +1° to 20°. One, with an external probe of 6m length for switching on and off the water pump, to set and control the temperature in the tank. The second digital thermostat controls the temperature in the water bank.

In addition to the conventional water cooling technology with an ice bank, a water and glycol mixture can be used, allowing the user to set the cooler temperature down to -6 °C without the risk of freezing. This makes the cooler ideal for homebrewing or small breweries, where it regulates the fermentation process.

AS TECHNOLOGY – Water cooling technology with an ice bank, where full ice supply provides maximum cooling performance.

GREEN LINE – The LINDR GREEN LINE technology is environmentally friendly thanks to the use of the eco-friendly refrigerant R-290. Thanks to this design, each product achieves 20% higher energy efficiency and 20% lower power consumption. We have introduced an energy saving system in the production.

OUTPUT – The AS-110 NEW GREEN LINE tapping equipment, with its increased continuous output, allows for the continuous serving of quality chilled beverages in quantities corresponding to their numerical marking in liters.

IMMERSION PUMP – The built-in stirrer ensures an even temperature throughout the water bath. If required, the stirrer can be modified and used as an after cooling pump with a discharge of 1.2 m.

CONSTRUCTION AND SERVICE – The modern layout of the cooling technology guarantees easy accessibility for any service and maintenance.

EQUIPMENT – Standard features include a thermostat for smooth and precise beverage temperature control, a cooling loop and quick couplers.

COMPACT DESIGN – The AS series coolers have the best performance, size and price ratio on the market.

Technical details

COOLING POWER OF THE COMPRESSOR (HP)

1/3

COOLING POWER OF THE COMPRESSOR (W)

860

MAXIMUM COOLING CAPACITY TO 0°C / TK 45°C (L/HOUR)

110

CONTINOUS COOLING PERFORMANCE (L/HOUR)

60

THERMAL GRADIENT ΔT(°C)

10

ICE BANK (KG)

10-20

DISPLACEMENT OF RECIRCULATION PUMP (M)

6

RECIRCULATION CONNECTION

1/2

NUMBER OF COOLED BEVERAGES

4

LENGTH OF COOLING COILS (M)

2X14, 2X11

DIAMETER OF COOLING COIL (MM)

7X8

POWER (W)

621

AMPERAGE (A)

2,70

NET WEIGHT (KG)

31.0

REFRIGERANT TYPE

R290

VOLTAGE (V)

220-240V 50Hz~1

BEVERAGE CONNECTION

SPEEDFIT FITTINGS 9,5mm (3/8")
